| Quantity: | |
|---|---|
Item | 50m³/h Counter Flow Closed Closed Tower | |
Model | NCT-50TB | |
Flow | m3/h | 50 |
Inlet Water Temperature | ℃ | 37 |
Outlet Water Temperature | ℃ | 32 |
Ambient Wet Bulb Temperature | ℃ | 28 |
Cooling Capacity | kcal/h | 250000 |
Overall Dimensions (length x width x height) | mm | 2350×1500×3310 2800(With Spray Water Pump)×1500×3310 |
Design Pressure | Mpa | 1.2 |
Test Pressure | Mpa | 1.6 |
Water Floating Rate | % | 0.01 |
Net Weight | kg | 1180 |
Running Weight | kg | 2450 |
| Voltage | 3Phase、50HZ、380V | |
| Motor Protection Grade | IP55 | |
| Motor Insulation Grade | ||
| Bearings | Japan NSK oil-free and maintenance-free | |
| Diameter of Water Pipe (Into/Overflow/Drain) | mm | DN25/ DN50/ DN50 |
| Diameter of Water Pipe （Inlet/Outlet） | mm | DN100*2 |
